GRAND G380N
TECHNICAL DATA
| Length overall | 360 |
| Length internal | 240 |
| Width overall | 185 |
| Width internal | 94 |
| Tube diameter | 45 |
| № of chambers | 3 |
| Tube material | PVC / Hypalon |
| Board height | - |
| Draft maximum (when fully loaded) | - |
| Dry boat weight | 180 |
| Loading capacity | 650 |
| Załoga | 5 |
| Built-in fuel tank capacity (l) | 42 |
| № of motors | 1 |
| Engine recommended (HP) | 30 |
| Engine max (HP) | 40 |
| Engine weight max | 115 |
| Engine shaft length | 508 |
| Midsection / aft deadrise (degrees) | 17°/15° |
| Hull type | RIB |
| Boat design category | C |
| Stowed dimensions of package №1 (cm×cm×cm) | 358×160×89 |
| Stowed dimensions of package №2 (cm×cm×cm) | 90×95×85 |
| Transport gross weight (kg) | 280 |
SCHEME OF COMPARTMENTS
1 – Bow compartment
2 – A compartment in the steering console
3 – Large aft locker
GALLERY
SPRZĘT
SPRZĘT STANDARTOWY
- Reinforced fiberglass hull of "Medium V" type with transom extension
- Inflatable balloon with fiberglass tips, PVC (Germany), Light-Gray, 1100 g / m²
- Bow step plate with nav lights, pull-up cleat
- Roomy nose compartment with soft removable cushions
- Steering console with front seat and locker, handrail, windshield and cup holder
- Mechanical steering system
- Stern sofa with soft back / Spacious aft compartment
- Antiskid deck surface
- Drainage system
- Hull ventilation system
- Mooring and towing knots
WYPOSAŻENIE DODATKOWE
- Overpressure valve
- Electric package
- Fuel system with tank (42 lit)
- Fuel level meter
- Removable side seat package
- Keel protector
- Tube protector
- Overall cover
- 2-arch collapsible bimini top
OUTBOARD MOTORS
YAMAHA F40FETL
|
YAMAHA F30BETL
|
YAMAHA F25GETL
|
|
|---|---|---|---|
| Engine type | 4-Stroke, SOHC, In-Line 3 | 4-Stroke, SOHC, In-Line 3 | 4-Stroke, SOHC, In-Line 2 |
| Displacement | 747 cm³ | 747 cm³ | 432 cm³ |
| Bore × Stroke | 65.0 × 75.0 mm | 65.0 × 75.0 mm | 65.0 × 65.1 mm |
| Max. prop shaft output | 29.4 kW / 40 hp | 22.1 kW / 30 hp | 18.4 kW / 25 hp |
| Fuel induction system | Electronic Fuel Injection (EFI) | Electronic fuel injection | Electronic Fuel Injection (EFI) |
| Lubrication system | Wet sump | Wet sump | Wet sump |
| Długość Dead-wood | L: 536 mm (21.1 inch) | L: 536 mm (21.1 inch) | L: 553 mm (21.8 inch) |
| Waga | 98.0 kg | 98.0 kg | 64.0 kg |
| Engine Start | Electronic Starter | Electronic Starter | Electronic Starter |
| Steering | Remote Control | Remote Control | Remote Control |
| System regulacji trymu i nachylenia | Power trim and tilt | Power trim and tilt | Power trim and tilt |
| więcej informacji | więcej informacji | więcej informacji |
Kolor obudowy
Kolor balonu
Dekor (opcje tapicerki)
Kolor powierzchni pokładu
Koło sterowe
Standardowe wyposażenie
-
Reinforced fiberglass hull of "Medium V" type with transom extension; WhiteInflatable balloon with fiberglass tips, PVC (Germany), Light-Gray, 1100 g / m² (3 air filling valves, fenders with water deflector, two rear safety rails, 1 bow and 6 side safety handles)Bow step plate with soft back, nav lights and pull-up cleatRoomy nose compartment with soft removable cushionSteering console CL-06 with front soft seat, compartment and handrailMechanical steering system (T67), steering cable (M58)Steering wheelStern sofa with soft backSpacious aft compartmentCorrugated hose in between decks space for flush-mounted communicationsAntiskid deck surfaceDrainage system (self-draining cockpit with non-return valves and drain plug)Hull ventilation systemTwo fodder cleat1 bow and 2 rear stainless U-boltsU-bolts lifting stainless steelTwo D-shaped towing rings on the balloonTwo assembling oars, suitable for inflatable boatsProfessional foot pump BRAVO-8Repair kit and user manual
Wyposażenie fabryczne
Wyposażenie dodatkowe
Konfigurator - Karta katalogowa - Zestaw zaburtowy Yamaha (Mechanical Electronic Control)
-
i
6Y8 Round Tachometer Kit, Flush Mount 6X3 Remote Control (left side), Panel Switch Assy Single, Main Harness 10P, Remote Control Cabels, Water/Fuel Separator Filter, Y-COP Kit
6Y8 Round Tachometer Kit, Flush Mount 6X3 Remote Control (left side), Panel Switch Assy Single, Main Harness 10P, Remote Control Cabels, Water/Fuel Separator Filter, Y-COP Kit
-
i
6Y8 Round Tacho + Speedo/FMM Kit, Flush Mount 6X3 Remote Control (left side), Panel Switch Assy Single, Main Harness 10P, Remote Control Cabels, Water/Fuel Separator Filter, Y-COP Kit
6Y8 Round Tacho + Speedo/FMM Kit, Flush Mount 6X3 Remote Control (left side), Panel Switch Assy Single, Main Harness 10P, Remote Control Cabels, Water/Fuel Separator Filter, Y-COP Kit
-
Музыкальная аудиосистема Hertz (75Wx2) i
-
Lowrance HDS-7 LIVE – Chartplotter / echo sounder with sensor Active Imaging 3in1™ i
-
Lowrance HDS-7 Carbon – Chartplotter / echo sounder (without sensors) i
-
Lowrance Elite-7 Ti² – Chartplotter / echo sounder with sensor Mid/High/TotalScan™ i
-
Lowrance HOOK² 7 TripleShot — Sounder / Chartplotter i
-
Lowrance HOOK² 7 SplitShot — Sounder / Chartplotter i
-
Lowrance HOOK² 5 TripleShot — Sounder / Chartplotter i
-
Lowrance HOOK² 5 SplitShot — Sounder / Chartplotter i
-
Battery 12V 75Ah i
-
Cockpit boat lighting i
-
Led underwater lights i
Wyposażenie standardowe: 52 751 zł Wewnątrz | Zewnątrz: 0 zł equipment: 0 zł Silnik zaburtowy: 0 zł Wyposażenie dodatkowe: 0 zł Przyczepa: 0 zł SUMA: 52 751 zł ZNIŻKA: * - 0 zł CENA ZE ZNIŻKĄ: 0 zł
